Product parameters
| Model | Max. hook load kN(Ib) | Rated HP, DrawworkskW(hp) |
|---|---|---|
| BE400 | 1800(404600) | 600(800) |
| BE550 | 2500(550000) | 735(1000) |
| BE770 | 3500(770000) | 1100(1500) |
| BE1100 | 5000(1100000) | 1470(2000) |
Drilling Equipment
Technical profile
High stability: The offset of drilling rig wellhead center is just 50% of similar type normal drilling rig under the heavy load.
At a glance
Key specifications
BE4001800(404600) / 600(800)
BE5502500(550000) / 735(1000)
BE7703500(770000) / 1100(1500)
BE11005000(1100000) / 1470(2000)
The available technical data for Substructure for ZJ90DB Double lifting drilling rig covers BE400, BE550, BE770, BE1100. Use these fields to compare the listed configuration with the project duty, site interface and delivery requirements before requesting a final quotation.
High clear height: Double-lifting type, rig floor height is 13.7m,the clear height is 12m.
Lightweight mast raising up: Lifting load is less than 1800KN.
Raising up Substructure remotely, hydraulic drawworks remote raising up with high safety.
Strong adaptability: The drawworks is installed on the rig floor, which isconducive to cluster well operation and transfer of large modules between well sites.
Innovative pipe operation process, tripping speed is up to 25 strings/h，improving pipe string handling efficiency by more than 20%.
One-key operation system realizes the pipe string processed operation.
Automatic coordinate alignment removes the effect of interferences.
Request technical details ?Specification review
Confirm the drilling equipment duty for Substructure for ZJ90DB Double lifting drilling rig before quotation.
Substructure for ZJ90DB Double lifting drilling rig is intended for onshore drilling, deep-well work and location-specific well construction. Review the actual well program, site interface and operating environment before approving a final technical configuration.
